Led Indicators

Level Indicators are of light weight, compact, rugged & field proven. All Indicators are provided with span & zero adjustment. Current consumption shall be between a few Microamperes to Milliamperes depending upon the model.

LED Type Level Indicators Model LLI-10 & LLI -12
Overall Dimension 48 x 96 x 60 or 110 mm
Input Signal 3-wire-Resistance from Transmitter (Resistance Value depends on Range)
Display 3 mm dia LED-11 nos- 10 for Level and 1 for Power On.
Range 0 to 100%, in 10 equal steps of Height i.e, Millimetres or Litres
Mounting Flush Panel or Projection
Level Indicator Model DPI-480
Overall Dimension 48 x 96 x 60 or 110 mm
Mains Power Supply 230 VAC / 24 VDC
Input Signal 4 to 20 mA
Loop Supply 24VDC - Built in
Display 0.5" Seven Segment LED, 3 1/2" or 4 digits.
Unit of Display 0-100%, Millimetres, Litres as required
Mounting Flush Panel
Level Indicator Model DPI-48
Overall Dimension 48 x 96 x 60 or 110 mm
Mains Power Supply 230 VAC / 24 VDC
Input Signal Resistance
Display 0.5" Seven Segment LED, 3 1/2" or 4 digits.
Unit of Display Millimetre i.e., Height of Liquid column.
Mounting Flush Panel
Level Indicator Controller Model LC 504/2F
Overall Dimension 96 x 96 x 110 mm
Mains Power Supply 230 VAC /12 or 24 VDC
Input Signal 4 to 20 mA
Display 0.5" Seven Segment LED, 3 1/2" or 4 digits.
Unit of Display 0-100% /Millimetres / Litres
No of Set Points 2
Set Point adjustment Push Button / Potentiometer
Output 2 change over Relay contacts-rated 5 Amps at 230 VAC resistive.
Mounting Flush Panel
